Dream Machine Pro (UDM-Pro)
Supplied and installed · Charleston & the LowcountryUbiquiti UniFi · UDM-Pro
Dream Machine Pro
10G Cloud Gateway with 100+ UniFi device / 1,000+ client support and 3.5 Gbps IPS routing.
In short
Includes full UniFi application suite for device management
3.5+ Gbps routing with IDS/IPS
(1) 10G SFP+*, (8) GbE RJ45 LAN ports
(1) 10G SFP+*, (1) GbE RJ45 WAN ports
3.5" NVR HDD bay
UniFi Power Backup ready
1.3" touchscreen- *Pair with an official SFP+ Module or SFP+ to RJ45 Adapter for the best experience.
Full specifications
Manufacturer data for the UDM-Pro.
Overview
| Dimensions | 442.4 x 43.7 x 285.6 mm (17.4 x 1.7 x 11.2") |
| Managed UniFi Devices | 100+ |
| Managed Cameras | (24) HD (14) 2K (8) 4K |
| Managed Access Hubs | 150Please note, Reader Pro and Intercom quantities must be below Protect supported camera limits. |
| Simultaneous Users Connected | 1,000+ |
| Max. WAN Port Count | 8 |
| Default WAN Ports | (1) 10G SFP+ (1) GbE RJ45 |
| Port Layout · 1 GbE RJ45 | 9 (1G/100M/10M) |
| Port Layout · 10G SFP+ | 2 (10G/1G) |
| IDS/IPS Throughput | 3.5 Gbps |
| Form Factor | Rack mount (1U) |
| Redundancy | Shadow Mode (VRRP) Gateway Failover DC Power BackupEnable DC power backup using UniFi RPS |
Security
| IDS/IPS Signatures | 55,000+ with CyberSecure |
Networking
| MAC Address Table Size | 4,000 |
Hardware
| NVR Storage | (1) 3.5" NVR HDD bay |
| Max. Power Consumption | 33W |
| Power Method | (1) Universal AC input, 100–240V AC, 50/60 Hz (1) USP-RPS DC input |
| Power Supply | AC/DC, internal, 50W |
| Supported Voltage Range | 100–240V AC |
| Heat Dissipation | 112 BTU/hr |
| Processor | Quad-core ARM® Cortex®-A57 at 1.7 GHz |
| System Memory | 4 GB |
| On-board Storage | 16 GB |
| Weight | 3.9 kg (8.6 lb) |
| Enclosure Material | Aluminium CNC, SGCC steel |
| Mount Material | SGCC steel |
| LCM Display | 1.3" touchscreen |
| Management | Ethernet Bluetooth |
| Button | (1) Factory reset |
| ESD/EMP Protection | Air: ± 15kV, contact: ± 8kV |
| Ambient Operating Temperature | -10 to 40° C (14 to 104° F) |
| Ambient Operating Humidity | 5 to 95% noncondensing |
| Certifications | CE, FCC, IC, Anatel: 01136-20-08356, SRRC |
What the install covers
The gateway routes, firewalls and runs the VPN, and it is where the controller for your switches, access points, cameras and doors lives.
Cutovers are staged and configured before anything is unplugged, then swapped in a window where an outage costs nothing. Firewall rules and network separation - guests, card terminals and cameras off the same network as your files - come after the line is up.
Questions we get asked
Do these need a subscription to keep working?
No. UniFi devices are managed from a console you own, with no per-device licence required to keep them running.
Do you supply the hardware as well as install it?
Yes - equipment and installation are quoted together as one job.
Do you work outside Charleston?
We cover Charleston, Mount Pleasant, North Charleston, Summerville, Daniel Island and the surrounding Lowcountry.
Get a price on the UDM-Pro
Tell us the building and what it has to cover. We quote the equipment and the installation together.
