Network Video Recorder Pro (UNVR-Pro)
Supplied and installed · Charleston & the LowcountryUbiquiti UniFi · UNVR-Pro
Network Video Recorder Pro
A 2U-sized video recorder with (7) 2.5/3.5" HDD bays that can provide up to 60 days of storage for (24) 4K cameras or (70) Full HD cameras.
In short
(7) 3.5" HDD / SSD support
(1) 10G SFP+ uplink and (1) GbE RJ45 port
Data protection with RAID storage technology
DC power backup-ready
1.3" touchscreen for management
Full specifications
Manufacturer data for the UNVR-Pro.
Overview
| Dimensions | 442 x 325 x 87 mm (17.4 x 12.8 x 3.4") |
| Managed Cameras | (70) HD (35) 2K (24) 4K |
| Managed Access Hubs | 150Please note, Reader Pro and Intercom quantities must be below Protect supported camera limits. |
| Storage Capacity | (7) 2.5/3.5" drive bays |
| Networking Interface | (1) 10G SFP+ port (1) GbE RJ45 port |
| Form Factor | Rack mount (2U) |
| Management Application | UniFi Protect UniFi Access UniFi Connect |
Hardware
| Hard Drive Capacity | (7) 2.5/3.5" HDD / SSD support |
| Max. Power Budget for Drives | 135W |
| Max. Power Consumption | 160W |
| Power Method | (1) Universal AC input, 100–240V AC, 3A Max., 50/60 Hz (1) USP-RPS DC input, 11.5V DC, 13.91A |
| Power Supply | AC/DC, internal, 200W |
| Processor | Quad ARM® Cortex®-A57 cores at 1.7 GHz |
| Memory | 8 GB |
| Management | Ethernet |
| Display | 1.3" touchscreen |
| Weight | Without mounting brackets: 9.2 kg (20.3 lb) With mounting brackets: 9.5 kg (20.8 lb) |
| Enclosure Material | SGCC steel |
| Mount Material | SGCC steel |
| Ambient Operating Temperature | -5 to 40° C (23 to 104° F) |
| Ambient Operating Humidity | 5 to 95% noncondensing |
| Certifications | CE, FCC, IC, Anatel: 06697-21-08356 |
What the install covers
How far back you can scroll is set by camera count, resolution and disk, so it is sized around the answer you want.
Disks arranged so the archive survives one failing, and remote viewing set up so any camera comes up on your phone.
Questions we get asked
Do these need a subscription to keep working?
No. UniFi devices are managed from a console you own, with no per-device licence required to keep them running.
Do you supply the hardware as well as install it?
Yes - equipment and installation are quoted together as one job.
Do you work outside Charleston?
We cover Charleston, Mount Pleasant, North Charleston, Summerville, Daniel Island and the surrounding Lowcountry.
Get a price on the UNVR-Pro
Tell us the building and what it has to cover. We quote the equipment and the installation together.
